This page contains present day photos (Year 2000 to date) of Ontario's King's Highway 401, arranged by location from Tilbury easterly to Chatham. All photographs displayed on this page were taken by the Webmaster (Cameron Bevers), unless specifically noted otherwise. Click on any thumbnail to see a larger image!

Please note that all photographs displayed on this website are protected by copyright. These photographs must not be reproduced, published, electronically stored or copied, distributed, or posted onto other websites without my written permission. If you want to use photos from this website, please email me first for permission. Thank-you!

Page 12: Present Day King's Highway 401 Photographs (Tilbury to Chatham)


HWY 401 #640 - © Cameron Bevers             HWY 401 #641 - © Cameron Bevers

Left - Sign marking the new Hwy 401 Eastbound "ONroute" Service Centre at Tilbury. The new green ONroute logo will be utilized on highway signs to mark Ontario's new generation of Service Centres along Hwy 400 and Hwy 401. The company operating the ONroute Service Centres, HKSC Developments, is intending to use the ONroute name in an effort to re-brand their new Service Centres and differentiate them from the old, outdated service centres built in the early 1960s.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Facing east along Hwy 401 at the new Tilbury ONroute Service Centres. The original Tilbury Service Centres were built in 1964, but were demolished and rebuilt in 2009-2010. Both of the new Tilbury ONroute Service Centres were opened to the public on July 1, 2010, although some of the facilities remained under construction until September, 2010.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #642 - © Cameron Bevers             HWY 401 #643 - © Cameron Bevers

Left - New ONroute Service Centre Sign for the Tilbury South Service Centre on eastbound Hwy 401.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - The Tilbury South ONroute Service Centre was fully operational at the time this photo was taken in September, 2010.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #644 - © Cameron Bevers             HWY 401 #645 - © Cameron Bevers

Left - Queen Street Underpass on Hwy 401 in Tilbury. Both Hwy 401 structures were completed in 1960.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Northern side of the Eastbound Hwy 401 Structure over Queen Street in Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #646 - © Cameron Bevers             HWY 401 #647 - © Cameron Bevers

Left - Northern side of the Westbound Hwy 401 Structure over Queen Street in Tilbury. The westbound structure was rehabilitated several years ago.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Facing east along Hwy 401 from the Hwy 2 Overpass east of Tilbury. The ramps at this interchange are in a "Parclo B-2" configuration. A Parclo B-2 is a four-ramp freeway interchange, with ramps in two diagonally-opposing quadrants. This interchange type is characterized by traffic exiting from the freeway on a loop ramp on the far side of the grade separation.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #648 - © Cameron Bevers             HWY 401 #649 - © Cameron Bevers

Left - Hwy 2 Overpass on Hwy 401 east of Tilbury. Structure completed in 1963.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - The Hwy 2 Overpass east of Tilbury is a simply-supported steel beam structure. Due to the skew of the interchange, this structure is considerably longer than most other freeway overpasses in the area. The bridge is 88 metres (288 feet) in length.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #650 - © Cameron Bevers             HWY 401 #651 - © Cameron Bevers

Left - Facing west along Hwy 401 towards Windsor from the Hwy 2 Overpass east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Facing east across the Hwy 2 Overpass on Hwy 401 east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #652 - © Cameron Bevers             HWY 401 #653 - © Cameron Bevers

Left - Facing west across the Hwy 2 Overpass on Hwy 401 east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Close-up view of the steel handrail design of the Hwy 2 Overpass on Hwy 401 east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #654 - © Cameron Bevers             HWY 401 #655 - © Cameron Bevers

Left - Northwest quadrant ramps at the Hwy 2 & Hwy 401 Interchange east of Tilbury. The two ramps at the Hwy 2 Interchange also provide access to adjacent Jeannettes Creek Road. This is one of the only freeway ramps in Ontario that has an intersection on it between the freeway and the arterial highway crossing through the interchange. The ramps in the opposing southeast quadrant of this interchange are also in this unusual configuration.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Facing east along Hwy 2 towards Chatham from the Hwy 401 Interchange east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #656 - © Cameron Bevers             HWY 401 #657 - © Cameron Bevers

Left - Northwest ramp terminal at the Hwy 2 & Hwy 401 Interchange east of Tilbury. This ramp terminal also provides access to adjacent Jeannettes Creek Road.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Fingerboard signs marking the way from Hwy 2 to Jeannettes Creek Road, via the on-ramp to Hwy 401.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #658 - © Cameron Bevers             HWY 401 #659 - © Cameron Bevers

Left - Bilingual guide sign for Hwy 401 West at the Hwy 2 Interchange east of Tilbury.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Southeast quadrant ramps at the Hwy 2 & Hwy 401 Interchange east of Tilbury. These two ramps at the Hwy 2 Interchange also provide access to adjacent McKinlay Road, which intersects the ramps just before the freeway entrance. The ramps to Hwy 401 on the other side of this interchange are in a similar configuration, providing access to Jeannettes Creek Road.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #660 - © Cameron Bevers             HWY 401 #632 - © Cameron Bevers

Left - Ramp to eastbound Hwy 401 from Hwy 2 east of Tilbury, showing the at-grade intersection with McKinlay Road.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Facing north across the Bloomfield Road Overpass at Hwy 401 in Chatham.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #633 - © Cameron Bevers             HWY 401 #634 - © Cameron Bevers

Left - Facing south across the Bloomfield Road Overpass at Hwy 401 in Chatham.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Western side of the Bloomfield Road Overpass on Hwy 401 in Chatham. Structure completed in 1962.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #635 - © Cameron Bevers             HWY 401 #636 - © Cameron Bevers

Left - Approaching the Bloomfield Road Interchange on eastbound Hwy 401 in Chatham. The Bloomfield Road Interchange is the first exit on eastbound Hwy 401 beyond the Hwy 2 Interchange in Tilbury, which is 18 km to the west.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Close-up view of the steel handrail design of the Bloomfield Road Overpass on Hwy 401 in Chatham.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)





HWY 401 #637 - © Cameron Bevers             HWY 401 #638 - © Cameron Bevers

Left - Facing west towards the Bloomfield Road Interchange on Hwy 401 in Chatham.
(Photograph taken on September 14, 2010  -  © Cameron Bevers)

Right - Ground-mounted freeway exit sign on Hwy 401 for Bloomfield Road in Chatham.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)





HWY 401 #639 - © Cameron Bevers             HWY 401 #661 - © Cameron Bevers

Left - A forest of signposts greets motorists at the north ramp terminal at the Bloomfield Road Interchange. The MTO has recently introduced new composite freeway services signboards which will consolidate many of the individual signs and signposts used today at freeway interchanges.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)

Right - Facing east along the eastbound lanes of Hwy 401 towards London from the Bloomfield Road Overpass in Chatham. The Bloomfield Road Interchange is a "B-2 Parclo", with traffic exiting from the freeway on a loop ramp.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)





HWY 401 #662 - © Cameron Bevers             HWY 401 #663 - © Cameron Bevers

Left - Facing west along the westbound lanes of Hwy 401 towards Tilbury from the Bloomfield Road Overpass in Chatham.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)

Right - Charing Cross Road Overpass on Hwy 401 in Chatham. Structure completed in 1962.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)





HWY 401 #664 - © Cameron Bevers

Above - Facing east along the westbound lanes of Hwy 401 towards London from the Charing Cross Road Overpass in Chatham.
(Photograph taken on September 13, 2010  -  © Cameron Bevers)
